How Efficient are Heat Pumps for Commercial Businesses?
When well-maintained and functioning correctly, heat pumps in commercial buildings are highly efficient. However, the exact proficiency of a heat pump depends on the existing insulation in a building, the size and type of the heat pump itself, and the regularity of its upkeep. Each factor will inhibit the heat pump’s ability to work effectively, so it’s essential to consider every angle when choosing a system for installation.
How Do Heat Pumps in Commercial Buildings Work?
Commercial heat pumps use refrigeration cycles, similarly to an air conditioner. However, the function can also be reversed to warm a building as well as cool it.
- The heat pump extracts thermal energy from the air, ground, or body of water.
- A liquid refrigerant inside the pump converts the thermal energy into gas.
- A compressor then increases the pressure of the gas, significantly raising its temperature.
- Lastly, the heat is expelled into the indoor air or water-based heating system for circulation.
How is the Efficiency of Commercial Heat Pumps Measured?
The Coefficient of Performance (COP) measures the efficiency of a commercial heat pump. Because heat pumps work only by moving heat around, they have the potential to transfer more energy than they consume. Conversely, traditional heating systems generate heat, meaning they can only output the volume of energy equal to the input.
The calculation for the COP of a heat pump uses this simple formula:
COP = Heat Output (kW) ÷ Energy Input (kW)
A heat meter calculates the heat output, measuring the flow rate and water temperature difference when it enters and exits the system. Similarly, an electricity meter calculates the energy input.
What Factors Affect the COP of Heat Pumps in Commercial Buildings?
- Temperature Difference
A commercial heat pump’s efficiency depends on the difference between the source temperature (eg, the outdoor air) and the temperature you are trying to get the room to. The colder a room is, the more intensely the heat pump must work to achieve your desired temperature, significantly lowering its COP.
- The Type of System You Have Installed
Ground-source heat pumps generally have a higher COP due to the consistency of the ground temperature year-round. Air climates fluctuate significantly with seasonal changes, which heat pumps work overtime to counteract. So, ground-source heat pumps are usually more stable and constant than air-source alternatives.
- The Regularity of the Heat Pump’s Maintenance
Commercial heat pumps require routine maintenance to sustain their COP (Coefficient of Performance). Any issue that restricts heat exchange forces the system to work harder. This results in higher electricity consumption to deliver the same output.
The most important maintenance tasks are cleaning the heat exchanger coils (indoor and outdoor) and filters. These are simple jobs but essential for keeping the heat pump running efficiently.
It is also important to check the on/off temperatures across the heat exchangers. This provides valuable information about the refrigerant charge. If the refrigerant level is incorrect, the system’s performance and energy efficiency will drop. As a result, the heat pump may use more energy and run for longer periods to achieve the desired output.
Other essential checks include the fans, motors, thermostats, and sensors. A thermostat or sensor that is out of calibration can cause the system to deliver incorrect readings. This leads to poor performance, higher energy usage and unnecessary strain on the heat pump.
Why do Commercial Heat Pump Coils and Filters Have to be Regularly Cleaned?
While in heating mode, the coil struggles to absorb heat from the air. And when in cooling mode, the coil can not release heat effectively. Similarly, the filters accumulate dirt, dust, and debris over time, causing an insulating barrier and interfering with the heat transfer rate.
How do Refrigerant Levels Affect the COP of a Commercial Heat Pump?
Heat pumps use a precise amount of refrigerant, which allows them to function optimally. Unidentified leaks can cause the system’s pressures and temperatures to fall out of the optimum range. Additionally, the compressor has to work harder to circulate the insufficient refrigerant levels, substantially reducing heat transfer capacity.
How Often Should the Components of a Commercial Heat Pump be Inspected and Calibrated?
You should have the components of a commercial heat pump inspected and calibrated biannually. However, depending on the demands of your operations, more frequent maintenance appointments might be necessary. You should employ a certified contractor once a year to recalibrate the thermostats, controls, coils, refrigerant levels, electrical connections, and moving parts. However, filters should be cleaned and replaced every 1-4 months, more regularly in high-traffic areas.
COP vs. SCOP for Commercial Heat Pumps
COP is the instantaneous measure of efficiency, and SCOP is a long-term efficiency measure over an entire heating season. For businesses, SCOP can measure the extended efficacy of a commercial heat pump system, accounting for a range of variables, including:
- Fluctuating outdoor temperatures and how the commercial heat pump’s efficiency changes with seasonal shifts.
- Partial load performance factors how efficiently the heat pump operates when it is not running at full capacity.
- Defrost cycles to calculate the energy consumed in cold weather.
The calculation for the SCOP of a heat pump uses this simple formula:
SCOP = Total Energy Input During Season (kWh) ÷ Total Heat Output During Season (kWh)
SCOP provides a more reliable basis for comparing heat pump models and calculating your return on investment.
How Does Building Insulation Affect the Efficiency of Commercial Heat Pumps?
Well-placed building insulation minimises heat loss in the winter and keeps heat out in the summer, significantly benefiting the efficiency of your commercial heat pump. A poorly insulated building allows warmth to escape quickly, forcing the heat pump to run at higher speeds more frequently for the same heat output. Proper insulation could even allow you to purchase a smaller system with lower running costs, which may offer a higher return on investment long-term.
The key areas of your building’s envelope to focus insulation improvement on are:
- Walls
- Roof and Ceilings
- Windows and Doors
- Floors
